EVLINK HVCH QA01 Series: Independent R&D with a Background from the University of Shanghai for Science and Technology
- It is designed to be environmentally friendly, with low emissions and energy-efficient operation.
- The heater is equipped with built-in diagnostics and self-monitoring capabilities, allowing for quick and accurate troubleshooting.
- It can be easily integrated into existing automotive heating systems without major modifications or disruptions.
- The High Voltage Heater Automotive is engineered to withstand voltage fluctuations and surges, ensuring stable and reliable heating performance.
Product Introduction:
The EVLINK HVCH QA01 series is a high-voltage PTC heater co-developed by the EVLINK team in collaboration with the University of Shanghai for Science and Technology. This heater not only boasts a unique control technology but is also entirely designed in terms of structure by EVLINK.
Through this dynamic blend of features and benefits, the EVLINK HVCH QA01 series truly stands as a reliable, efficient, and advanced high-voltage PTC heater choice in the market, not only owing to its distinct R&D background but also for its proven excellence in performance and reliability in real-world applications.
Specification:
| HVCH QA01 Series |
| Heat Output | 15-25kW |
| HV Voltage Range | DC 250-870V |
| LV Voltage | DC 24V nominal |
| Efficiency | > 95 % |
| Controllability Steps | 100W |
| Dimensions | 365*313*123mm |
| Weight | 9kg |
| Temperature Range for Heating | -40 to 90 ℃ |
| Temperature Range for Ambient | -40 to 125 ℃ |
| Communication | CAN or LIN2.1 |
| Dielectric Strength | 3500 V (DC) |
| IP Protection Class | IP 67 |
| EMC | ECE R10 Rev. 5 |
| Insulation Resistance | ＞500MΩ |
| Service Life | 10 years or 10,000 heating hours |
Product Attributes
ØIndependent R&D: The control and structure of the heater are both developed by the EVLINK team.
ØDirect Supply: EVLINK offers a direct product supply to clients, without the interference of middlemen.
ØExperimental Reports: EVLINK provides comprehensive experimental reports for all its products.
Applications
In the cold winters of Korea, EVLINK's 20KW heater has been adopted by a majority of electric buses, rapidly elevating the temperature within the cabin, ensuring a comfortable environment for passengers.
Our Services
EVLINK has service networks in both China and Korea. They regularly train and guide bus drivers and also frequently inspect the working conditions of the heaters.
Competitive Advantages
R&D Background: Product co-developed with the University of Shanghai for Science and Technology.
Direct Supply: Direct product provisioning by EVLINK. Widespread Adoption: Chosen by a majority of electric buses in Korea. driving range without wasting energy .
Precise and stepless controllability: better performance and optimized power management.
